Table 979. Electron diffraction of dysprosium silicides.

Ytterbium silicides Electron diffraction
YbSi2-x Orientation relationship of (10-10)YbSi2-x/(11-2)Si
Diffraction pattern along the [10-10]YbSi2-x/[11-2]Si direction of a cross-sectional YbSi2-x/(111)Si sample after annealing at 300 °C for 30 min. [1]
Orientation relationship of (10-10)YbSi2-x/(11-2)Si
Orientation relationship of (10-10)YbSi2-x/(11-2)Si from a sample after annealing at 300 °C for 30 min. [1]
































[1] Lih J. Chen, Silicide Technology for Integrated Circuits, 2004.






=================================================================================
